Full Description
Accommodating Your Music
TEAC have designed the CD-P750DAB to be a highly versatile music source beyond its simple CD capabilities. Along with the slot-drive disc tray, you are also given reception for DAB+ and FM radio, along with high-quality Bluetooth links. USB and SD memory card playback is also accommodated, supporting files formats including MP3, WAV, AAC and WMA. The CD-P750DAB lets you listen to music the way you want.
Easy Audio Recording
In addition to USB and SD card file playback, the TEAC CD-P750DAB can also be used to record audio from CD and radio directly to USB and SD / SDHC cards without having to connect to an external computer. Simply press dub and then play the content you want to record. All dubbing functions can be controlled from the front panel, offering an easy solution for digitalising your cherished music collections.
Bluetooth Control
Along with the front 6.3mm jack input, you can also connect your mobile or handheld portable audio device to the CD-P750DAB by Bluetooth, letting you sit back and browse your music catalogue from anywhere in your listening room. Using the latest Bluetooth 5.1, you can connect via higher-quality codecs from AAC to aptX HD, ensuring minimised signal loss between your device and the receiver along with broader compatibility.
Key Features
- CD slot-load mechanism enables seamless quick loading
- Supports playback from CD, USB and SD card along with file formats including WAV, MP3, AAC amd WMA
- Allows recording from DAB+ / FM tuner and CD audio to USB and SD memory devices without external computer
- Up to 20 radio station presets for both FM and DAB+ frequencies
- Supporting Bluetooth 5.1 and compatible with SBC, AAC, aptX and aptX HD codecs
- Separate tuner output allows alternate media source to connected at the same time as radio
- Front panel 6.3mm auxiliary input allows easy connection and playback for handheld portable music devices
- Headphone jack enables private listening
What’s in the Box?
- x1 TEAC CD-P750DAB
- x1 AC power cable
- x1 Remote Control (RC-1336)
- x1 FM antenna
- x1 Owner’s manual
 
Specifications
Audio Codecs & Formats
| CD formats | CD
CD-R
CD-RW |
|---|---|
| Bluetooth codecs | SBC
AAC
aptX
aptX HD |
| Supported file formats | MP3
WMA
WAV
AAC |
| Bluetooth Version | 5.1 |
Audio Output
| RCA (Output level & impedance) | 2 (-10dBV (0.316Vrms) to +6dBV (2.0Vrms). 200Ω) |
|---|---|
| 6.3mm jack (Power & impedance) | 1 (20mW + 20mW (THD+N 0.1 or less, into 32Ω load)) |
| Coaxial | 1 |
| Optical / Toslink | 1 |
| USB 2.0 | 0 |
Radio Reception
| Reception type | FM
DAB+ |
|---|---|
| Presets | 20 FM
20 DAB+ |
| Radio frequency (FM) | 87.5 – 108MHz |
| Radio frequency (DAB/DAB+) | Band III, 174 – 240MHz |
Operations
| Power | AC 100 to 240V, 50/60Hz |
|---|---|
| Power consumption | 20W |
| Operating temperature range | 5 – 35°C |
General Specifications
| Product dimensions (W x D x H) | 48.26 x 29.71 x 5.88cm |
|---|---|
| Packaged dimensions (W x D x H) | 64.5 x 50 x 29cm |
| Net weight | 3.6kg |
| Gross weight | 16kg |
| Controls | On device
Remote control |
