Full Description
What’s in the Box?
- REL HT/1003 MKII Subwoofer, Black
- Mains lead
- User manual
Specifications
| Type | Closed box, front-firing driver |
|---|---|
| Active driver size and material | 10 in., 250mm long-throw, CarbonGlasâ„¢ cone structure, inverted carbon fibre dust cap, steel chassis |
| Passive radiator size and material | N/A |
| Low frequency extension | -6dB at 24 Hz |
| Input connectors | Dual-purpose low-Level stereo RCA or LFE RCA |
| Output connectors | Daisy Chain low-Level stereo RCA or LFE RCA |
| Power output | 300 watts (RMS) |
| Amplifier type | NextGen5 Class D |
| Wireless capability | HT Air Wireless (Optional), Zero Compression Single Large Scale Integrated Chip |
| Dual parametric filter | N/A |
Protection System
| Fully electronic set safe | Yes |
|---|---|
| D.C. fault | Yes |
| Output short | Yes |
| Mains input voltage | 220-240 volts, 110-120 volts for certain markets |
| Fuses | 2.5 Amp semi delay 230b, 5 Amp semi delay 115b operation |
Appearance
| Dimensions (W x H x D) | 12.5 x 13.7 x 13.8 (318mm x 347mm x 351mm) |
|---|---|
| Net weight | 34.2lbs. (15.5kg), shipping weight 41 lbs. (18.6 kg) |
| Finish | Horizontally Oriented Lined Grained Black Composite Cabinet, 15mm Top Plate, finished in 5 coats of Hand rubbed High Gloss Black Lacquer |
