Full Description
Please Note
Due to the specialist nature of this product, a member of our customer service team will make contact following your order to provide technical assistance and information before confirming delivery.
Beautifully designed for your home
The elegant design of the Platinum Series’ 3G speakers is completely new and crafted with precision engineering and incredible attention to detail. Courtesy of Monitor Audio’s outstanding quality control procedures, you can be sure that this product will both perform well and bring a sophisticated look to your home.
Clear, lifelike sound
Whether you’re watching a film or playing music, Monitor Audio’s MPD III high-frequency and RDT III mid and bass drivers deliver clear, crisp and powerful audio. With optimised rear volume, the MPD III transducer ensures that there is minimal audio ripple in the audible frequency range, ensuring the truest and most accurate sound is produced. Hear vocals clearer than ever before thanks to the tight and articulate delivery from the new RDT III cone.
Dual-layer isolation
Eliminate unwanted vibrations for pure sound. Individually cast aluminium driver holders allow for two layers of isolation between the drivers and the cabinet. This can be controlled using through-bolt driver tension rods that can easily be adjusted from the rear of the speaker. Using this, you can ensure that only the cleanest sound is produced.
Features
- 1 x MPD III high-frequency transducer for a larger, clearer, and more lifelike sound
- 1 x 3” RDT III mid-range driver for incredible levels of clarity
- 2 x 6” RDT III bass drivers for exceptional scale and depth
- The ultimate centre channel for the ultimate Platinum Series 3G theatre system
- Sealed cabinet configuration for in-cabinet or close to wall placement
- Perfect for high performance hi-fi systems or home theatre
- Cabinets are embellished with etched inlays to highlight the craftsmanship
- Choice of three high-quality, elegant finishes: Piano Black, Piano Ebony and Pure Satin White
Audio
| System Format | 3-Way |
|---|---|
| Frequency Response, Free-Field (-6dB) | 48 Hz – 60 kHz |
| Frequency Response, In-Room (-6dB) | 30 Hz – 60 kHz |
| Sensitivity (2.83 Vrms @ 1m, Free-Field | 88 dB |
| Bass Alignment | Sealed |
| Port Tuning Frequency | N/A |
| Crossover Frequency | LF/MF: 850 Hz, MF/HF: 3.5 kHz |
| Drive Unit Complement | 2 x 6″ RDT III bass driver, 1 x 2.5″ RDT III mid-range driver, 1 x MPD III tweeter |
Power & Impedance
| Nominal Impedance | 4 Ohms |
|---|---|
| Minimum Impedance (20 Hz to 20 kHz) | 4.0 Ohms @ 150 Hz |
| Continuous Power Handling(RMS into 4 Ohms, Pink Noise with 6dB Crest Factor) | 300 W |
| Recommended Amplifier Power (RMS into 4 Ohm, Music Signal) | 150 – 600 W |
Dimensions
| Dimensions (including Trims, Terminals & Outrigger Feet & Spikes) (H x W x D) (mm) | 225 x 630 x 325.7 |
|---|
Weight
| Weight (kg) | 25.4 |
|---|
Design
| Colour | Piano Black |
|---|
