Mission 778x Integrated Amplifier With Bluetooth, Black

Mission 778x Integrated Amplifier With Bluetooth, Black - Image 2

Mission 778x Integrated Amplifier With Bluetooth, Black - Image 3

Mission 778x Integrated Amplifier With Bluetooth, Black - Image 4

Mission 778x Integrated Amplifier With Bluetooth, Black - Image 5

Mission 778x Integrated Amplifier With Bluetooth, Black - Image 6

Mission 778x Integrated Amplifier With Bluetooth, Black - Image 7

Mission 778x Integrated Amplifier With Bluetooth, Black

Original price was: £370.00.Current price is: £99.99.

SKU: YXYUY 58320 Categories: Amplifiers, HiFi Separates

Free Shipping Worldwide
fast shipping
Safe Payments, the Smart Choice
Enjoy top quality items for less

Description
Reviews (0)

Full Description

Integrated Amplifier

The Mission 778x offers a Class-AB design so you can enjoy effective sound quality with low distortion levels. The 778x provides a low-noise 200VA toroidal transformer and a 2x15000uF reservoir capacity so you can enjoy a two-channel power output of up to 65W each. The preamp section immerses you in the sound with its low THD rating and a frequency response of 20Hz-20kHz, so all your favourite music genres are catered for. The 778x is even harnessed with a high-quality headphone amplifier that generates high-speed output signal transition so you can enjoy amazing audio quality.

High Performing DAC and Inputs

Connect all of your digital devices thanks to the USB, Coaxial, and dual Optical inputs, with up to three RCA inputs enabling excellent pairing with your analogue devices such as your turntable. The 778x provides Bluetooth 5.0, so you can stream all your favourite playlists on Spotify and Apple Music, straight from your smart devices. The built-in DAC gifts you with immersive audio thanks to the ES9018K2M chipset, the 32-bit HyperStream architecture and Time Domain Jitter Eliminator. Experience a sampling rate of up to 384kHz (PCM) and DSD256.

Great Design

The reliable, compact design allows for easy storage within any HiFi cabinet and also adds a voguish vibe to your home decor. The 778x provides two sturdy rotary controls so you can manage the volume as well as select the input sources. The white LED lights will also notify you what settings are currently selected.

Key Features

Class-AB design ensures Missions signature sound quality
A two-channel power output of up to 65W each transmits robust audio signals
Preamplifier allows for low distortion and a dynamic sound
The headphone amplifier provides high-speed output signal transition
The USB, Coaxial, and Optical inputs ensure direct connectivity to digital devices
The three available RCA inputs allow you to connect to analogue audio sources
Bluetooth 5.0 lets you wirelessly connect to your smart devices with aptX and AAC codecs
High-quality DAC generates immersive, high-speed digital to analogue sounds
The brilliant design ensures versatile positioning and ample control over your audio

What’s in the box?

The Mission 778x Integrated Amplifier
1 x Power Cord
1 x Remote Control
1 x Bluetooth antenna
User Manuals

Specifications

Model

Model	778X
General Description	Digital-to-Analogue Converter Stereo Amplifier
Design Philosophy and Core Technology	Integrated Amplifier (45 watts @8 ohms, 65 watts @4 ohms) ESS Sabre32 ES9018K2M Reference Chip Ultra-low Noise Digital Audio File Compability (384kHz PCM, DSD256) Bluetooth 5.0 (aptX / AAC) Support Dedicated High-performance, Low-noise MM Phono Stage Headphone AMP With High-speed Output Signal Transition USB Upgrade Support Large Tractile Controls With LED Level Indicators
Inputs	1 x Coaxial 2 x Toslink Optical 1 x PC USB 1 x Bluetooth (aptX/AAC) 2 x AUX 1 x RCA (Phono MM)
Outputs	1 x Coaxial 1 x Toslink Optical 1 x RCA (PRE Out)
Sampling Frequency	Optical / Coaxial: 44.1kHz-192kHz; PC USB 44.1kHz-384kHz(PCM) / DSD64, DSD128, DSD256

Preamplifier Section

Gain (max.)	+0dB (Line) +47dB (Phono MM)
Input Sensitivity	540mV (Line, Volume = 0dB); 2.5mV (Phone MM, Volume = 0dB)
Input Impedance	10K (AUX); 47K//100pF (Phono MM)
Total Harmonic Distortion (THD)	110dB (A-weighted)

DAC

D to A Converter	ESS Sabre32 ES9018K2M
Resolution	32-bit
Max. Sampling Frequency	Optical/Coaxial: 192kHz; USB: PCM 384kHz / 11.2896MHz (DSD256)
Total Harmonic Distortion (THD)
Output level (0dBFS, 1KHz)	2.1Vrms

Power Amplifier Section

Gain	+31dB
Rated Power Output	2 x 45W (@8ohms) 2 x 65W (@ 4 ohms)
Frequency Response (ref. 1kHz)	20Hz-20KHz (± 0.5dB)
Total Harmonic Distortion (THD)	108dB (ref. 45W, A-weighted)
Crosstalk @1K	>80dB (ref.1W)
Standby Power Consumption

Headphone Amplifier

Total Harmonic Distortion (THD)
Output Impedance	4.7 ohms
Load impedance	20-600 ohms

General

Dimensions (mm) (W x H x D)	236 x 98 x 380.6 mm
Carton Size (mm) ( W X H X D)	450 x 392 x 175 mm
Net Weight	6.3kg
Available colours	Black / Silver
Power requirements (depending on region)	220-240V, 50/60Hz; 100-120V, 50/60Hz
