Full Description
Specifications
Analog Audio
| Maximum Output Level | 1.8 VRMS. |
|---|---|
| Frequency Response | 8 Hz to 20 kHz (+0 / -0.3 dB); 44.1k and 48k sample rates
8 Hz to 40 kHz (+0 / -1.5 dB); 88.2k and 96k sample rates
8 Hz to 60 kHz (+0 / -3 dB); 176k and 192k sample rates |
| Signal to Noise Ratio | > 106 dB (A-weighted) |
| Total Harmonic Distortion + Noise | |
| Headphone Blend Mode | Switchable |
Digital Audio
| USB Interface (input) | Asynchronous
USB Audio Class 1 and 2. |
|---|---|
| Audio Format Supported | PCM Digital Audio |
| Sample Rates Supported | Apple computers: 44.1k, 48k, 88k, 96k, 176k, 192k, 352k, 384k
Windows computers: 44.1k, 48k, 88k, 96k, 176k, 192k, 352k, 384k (no drivers required with current computers: Windows 7 drivers available for download) |
| Bit Depths Supported | 16 bits
24 bits
32 bits |
| Digital Filter Options | Symmetrical
Asymmetrical Low
Asymmetrical High |
Input And Output
| Input | Mini USB Connector (from computer) |
|---|---|
| Outputs | Headphone (analog; variable) |
Size and Weight
| Dimensions | 120 x 44 x 12 mm (L x W x H) |
|---|---|
| Weight | 0.10kg |
