Full Description
Uni-Fi Reference
Defining The Standard For Performance And Style
Building on the success and performance of the Uni-Fi 2.0 series of speakers, Uni-Fi Reference is not merely a name, but the defining characteristic of a product that has been refined for maximum performance and style.
The Ultimate Centre Speaker
The new Uni-Fi Reference Series establishes a level of performance and cosmetics not associated at this price point. Designed to blend with traditional or contemporary styles.Β
- 3-Way Bass Reflex
- 47Hz – 35000Hz Frequency Response
- New Concentric Driver With Cast Chassis
- Newly developed 5.25β Aluminium Woofer with Cast Chassis
New Concentric Driver With Cast Chassis
A wide-surround tweeter enhances itβs low and high frequency extension allowing for improved blending with the midrange. An entirely new midrange driver with large diameter voicecoil, vented rear spider and new neodymium magnet allows for better excursion and control of midrange frequencies. A new cast chassis was designed to minimize reflections back to the cone resulting in better clarity
Newly Developed 5.25β Aluminium Woofer With Cast Chassis
Drastically improving low-end reproduction, this newly developed bass driver features a single piece compound curvature aluminium cone with a large rear vented magnet delivering improved linearity and better low frequency response of any previous Uni-Fi centre speaker.
Full Perimeter Bracing
Reducing the speaker cabinets influence on the audio quality the Uni-Fi reference line implements full perimeter bracing significantly reducing cabinet vibration and cabinet coloration.
Dual Flared Slot Vents
Our newly developed slot vents utilized both internal and external flares allowing for lower noise and high bass output for improved low frequency dynamics.
| Speaker Type | 3-Way Bass Reflex |
|---|---|
| Frequency Response | 47Hzβ35000Hz |
| Nominal Impedance | 6 Ohms |
| Sensitivity | 85db |
| Crossover Frequency | 240 / 1800Hz |
| Maximum Power Input | 140 Watts |
| Tweeter | 1β Soft Dome |
| Midrange | 4β Aluminium |
| Woofers | 2 x 5.25β Aluminium |
| Cabinet | CARB2 Rated MDF |
| Cabinet Finishes | Satin White with Oak Sides
Satin Black with Walnut Sides |
| Port | Dual Flared Slots |
| Binding Posts | Bi-Wire 5-Way |
| Dimensions (WxHxD) | 52.71cm x 18.5cm x 33.41cm |
| Net Weight | 13.2 kg |
