Aerofoil Cones
The Aerofoil cones featured in the DB series subwoofers are derived from the 800 Series Diamond. The ultra-light and rigid cones resist bending and flexing far longer than standard cones for increased durability and trouble-free service. Precise and stable bass is assured for complete immersion with every explosion or beat of the drum from your favourite movies and music. The single cone driver is housed in a sealed enclosure resulting in colour-free bass with minimal resonances and vibrations.
| Description | DB Series Subwoofer |
|---|---|
| Drive units | 1 x 250mm (10in) Aerofoil cone bass unit |
| Frequency range (-6dB) | 8.5Hz – 500Hz |
| Frequency Response -3dB (centred on the level at 100Hz) | 10Hz – 350Hz |
| Max power output | 1000W Class D Hypex amplifier |
| Rating power consumption | 195W |
| Input impedance | XLR 20kOhm
RCA 10kOhm |
| Signal to noise ratio | 82dB |
| Features | 1000W Class D Hypex amplifier 1 x 250mm (10in) Aerofoil-cone drive unit
Digital preamplifier with Dynamic EQ, App-based set-up and BT-LE control |
| Inputs | 2 x XLR
2 x RCA
2 x 3.5mm 12V trigger
RS-232 – 9-pin D connector |
| Dimensions | Height 377mm (14.8in)
Width 360mm (14.1in)
Depth 368mm (14.5in) |
| Net weight | 26kg |
| Product code | FP39640 |
