Full Description
the-ear.net best buy
“Not only is this a design that sounds very musical, they are also speakers that keep you listening to the music, and that’s probably the key for any design.”
Tweeter
The bespoke 25mm soft dome tweeter is designed by Acoustic Energy to work hand in hand with the 100 series bass driver – with optimum integration and tonal matching. This is combined with a Wide Dispersion Technology waveguide, making the crossover region between drivers audibly seamless, and the high-power neodymium motor assembly delivers distortion-free high-volume playback.
Drivers
The 100 series uses a 130mm bass/mid driver, developed using high power, a long excursion motor for great volume levels, and great bass extension. And with a doped paper cone, it enables a higher crossover point that allows for smoother mid-range and a seamless crossover with the tweeter – so all sound reproduction is high fidelity, detailed and musical.
Cabinet
The thin, 15mm high-density (HDF) enclosure has precisely tuned bracing, so harmful resonances are reduced while the body and substance are maintained. Smooth bass extension is enhanced with the rear slot porting, while inert mass-loading provides additional stability and acoustic damping.
Features
- Slim-line floor-standing speaker
- Achieves high SPL in a compact package
- 130mm mid-bass drive unit with long-throw motor system delivers full-bodied bass
- 25mm Wide Dispersion Tweeter fills your room with sound
- Vinyl veneer finish looks great in any space
- Grilles included providing protection and longevity for your speaker
| Dimensions (mm) | 860 x 165 x 250 (HxWxD) |
|---|---|
| Weight | 16kg (each) |
| Drive Unit | 130mm paper cone |
| Tweeter | 25mm fabric dome |
| Frequency Range | 41Hz – 26kHz |
| Sensitivity | 89dB |
| Peak SPL | 115dB |
| Power Handling | 175w |
| Crossover Frequency | 275Hz, 2.2kHz |
| Impedance | 6ohms |
| Design | 2.5-way |
| Grilles | Slim, cloth magnetic fit |
| Product code | AE52-09W-PAIR |
